Bouregreg et la Chouia hydraulic basin – Commissioning a Network of Hydro-Meteorological Stations – Morocco

Project summary

Service provided:  Commissioning a Network of Hydro-Meteorological Stations
Location:  Bassin hydraulique du Bouregreg et la Chouia
See google map
Client:  Agence du Bassin Hydraulique du Bouregreg et Chaouia (ABHBC)
Period of the service:  January 2017 - January 2020
Duration of service:  3 years
Sixense solutions used:

Images of the project

A densely populated zone exposed to floods

The Bouregreg and the Chaouia Rivers contains a high number of Morroco’s critical water assets including many dams, in a densely populated region..

In order to protect the cities and villages along the rivers, Sixense Morocco set-up a network of preventative water level radars systems, upstream of the inhabited zones. Thresholds and trigger levels were set-up, and alarms are automatically issued to the local authorities (via the ABHBC) in case of flood risks.





Assess and optimise water resources

Automated weather and hydrological stations, comprising of thermometers, anemometers, rain gauges, nearby stream, river or dam reservoir water level sensors, flowmeters and phreatic zone water level sensors, allow the ABHBC to gather comprehensive information about the water resources in the area and make fully informed decisions based on accurate data.

The monitoring information is processed and made available by GEOSCOPE, the data can also be handled using third party software and different analysis and calculation tools of the ABHCB or the Direction des Aménagements Hydrauliques. The Risk Management prediction tool commissioned in this part of Morocco, developed by the French company PREDICT, directly takes information from Geoscope thanks to a Predict module developed by Sixense Morocco.

Project Key figures

4 Complete Weather Stations
25 Water Level Radars
1 Data transmission using the GSM network and long-range radio spectrum
1 Geoscope, with data acquisition every 5min
